ServINS® W86X5-G4

It is a self-developed high-performance computing fully liquid cooled workstation, adopting a closed liquid cooling design, paired with the fourth/fifth generation Intel ® Xeon ® The Scalable series processor adopts CPU and GPU fully liquid cooled heat dissipation, and a self-developed noise reduction liquid cooled heat dissipation system. It is equipped with 4 liquid cooled GPU graphics memory units, which can reach up to 320GB and support up to 5940TFLOPS mixed precision computing performance. The overall noise during full load operation is less than 55dB. At the same time, it is equipped with a LCD display panel, which can monitor key parameters such as flow rate, water temperature, and fan speed in real time, easily cope with computationally intensive workloads, and help accelerate the landing of various professional applications such as AI and HPC.

Super performance

● 5th/4th Gen is designed specifically for AI, with each core equipped with AI acceleration capabilities, resulting in an 84% increase in general computing performance and a 14 fold improvement in AI training and inference performance;

● Supports DDR5 memory, with a maximum frequency of 5600MHz. With higher memory bandwidth, it improves computing performance. Compared with DDR4, DDR5 has a bandwidth increase of up to 66%.


flexible expansion

● The whole machine adopts a CPU+GPU fully liquid cooled integrated liquid cooling and heat dissipation system, with a noise level of less than 55dB during full load operation. The circulating air duct design, adjustable fan speed, closed circulating water circuit, and no risk of liquid leakage.

maintainability

● Fully sealed leak proof liquid cooling pipeline, equipped with intelligent LCD panel and SPD management system, can monitor the operating status, temperature, power consumption, fan and leakage alarm in real time, and eliminate hidden dangers.

processor
memory
Storage Expansion
PCIe Expansion
network interface
I/O interface
power supply
Overall dimensions
temperature range
system support
Supports 2 Intel chips ® Xeon ® 4th/5th Scalable series processors (Intel) ® C741 chipset)
16 DDR5 memory slots, with a maximum expandable capacity of 4TB
Supports DDR5 5600MHz RDIMM/LRDIMM
8 SATA3.0 interfaces
2 M.2 PCIe 4.0 x2 interfaces, supporting 2280/22110
Internally supports up to 4 3.5 "/2.5" SATA/SAS hard drives
4个PCIE5.0X16、2个PCIE5.0 X8
2 10 Gigabit RJ45 Ethernet ports
1 Gigabit RJ45 IPMI dedicated management network port
Front panel: 2 USB 3.0 ports, 1 Type-C port, 3 indicator lights, restart button, power button, real-time monitoring screen
Rear panel: 1 COM, 3 USB 3.0, 1 IPMI LAN, 1 USB 3.0 TYPEC, 2 10G LAN, 1 VGA
Standard 2600W Japanese brand module power supply (power supply can be selected according to the number of GPU cards)
Height 610mm * Width 300mm * Depth 640mm
Working temperature: 0 ° C-50 ° C (32 ° F-122 ° F);
Storage temperature: -20 ° C to 60 ° C (-4 ° F to 140 ° F);
Relative humidity for work/storage: 10% -95% (non condensing state of air at 35 ℃)
For specific detailed versions of mainstream systems such as Microsoft Windows, CentOS, Ubuntu, etc., please contact a sales representative or consult technical support
