INS-R2202-8I Universal Server

Category:Server
Innord (Shenzhen) Technology Co., LTD. (referred to as "Innord") has been a national high-tech enterprise focusing on the application,

Super performance

  • Supports Intel ®  xeon ®  Scalable processor

  • Strong computing performance, with a brand new 3 UPI interconnect architecture and a bus bandwidth of up to 11.2 GT/s

  • Supports DDR4 2933MHz memory frequency, with a 25% increase in memory bandwidth compared to the previous generation


flexible expansion

  • Supports 12 3.5-inch or 24 2.5-inch hard drives, compatible with NVMe SSDs, enabling the selection of storage resources

  • Onboard integrated network card, flexible expansion of OCP network card and PCI-E card, network configuration as needed


maintainability

  • Comprehensive coverage of multiple management protocols such as RedFish, IPMI, SNMP, etc

  • Full lifecycle intelligent operation and maintenance, IPMI deep fault diagnosis technology

  • Optional 80PLUS Platinum and Titanium Power Modules to Improve Energy Efficiency


processor
memory
Storage Expansion
PCIe Expansion
network interface
I/O interface
power supply
Overall dimensions
temperature range
system support
Supports 2 1st or 2nd generation Intel chips ® Xeon ® Scalable Processors(LGA3647)
8 DDR4 memory slots, maximum support 2TB Registered ECC DDR4 2933MHz
Comes standard with 8 2.5/3.5 "SATA/SAS hard drives, expandable to an additional 12
1 NVME M.2 3.0X4 2280/22110
2 PCIe 3.0 x16, 3 PCIe 3.0 x8,1 PCIe 3.0 x4 (in x8 slot)
2 integrated Gigabit Ethernet cards (RJ45 interface), optional 10G Ethernet card
1 VGA port
4 USB 2.0 ports(2 rear + 2 via header)
1 COM Ports (1 header)
Standard dual power 550W, can be upgraded to 800W/1300W or redundant gold medal power supply
87mm x 438mm x 557mm(H*W*D) (H*W*D)
Operating temperature from 0 ° C to 50 ° C (32 ° F to 122 ° F); -40 ° C -70 ° C (-40 ° F -158 ° F) non operating temperature
Microsoft Windows Server;Red Hat Enterprise Linux Server;CentOS Linux Server;Ubuntu;
SUSE Linux Enterprise Server VMWare ESXi 7.0u1 x64
